Cassette-Geko

Heating, cooling, and ventilation: effectively and quietly

Cassette fan coil units are designed for the climate control of rooms. They are installed above suspended ceilings as flush-mounted units. The 3 models available – the Single, Double, and Big Single versions – assure pleasant, comfortable room climate in summer and winter. Installation in the open space between the suspended ceiling and the floor slab above minimizes space requirements and saves costs.

Cassette-Geko Single
Cassette-Geko Big Single
Cassette-Geko Double
HyCassette-Geko with SWIRL technology

3 model sizes: Single, Double, Big Single
7 capacity ratings
2- and 4-pipe systems
250-1,700 m³/h
1-19 kW
Heating, cooling and ventilation

Single
Double
Big Single
HyCassette-Geko (SWIRL® Technologie)

Especially compact suspended-ceiling model
Dimensions: 575 x 575 mm, covering enclosure 660 x 660 mm
It matches the installation sizes made available in a conventional rectangular-grid ceiling

An especially compact suspended-ceiling model, which makes it the smallest of the Cassette range of fan coil units. With its dimensions, it matches the installation sizes made available in a conventional rectangular-grid ceiling.

Matches the dimensions of two Single units
With 2 fans, 2 heat exchangers, 2 filters, and 2 air-intake openings
Dimensions: 1,175 x 575 mm, covering enclosure 1,260 x 660 mm
Also fits the dimensions of a conventional rectangular-grid ceiling

This model is the right one where greater capacity is required. Truly a double: with 2 fans, 2 heat exchangers, 2 filters, and 2 air-intake openings, the Double model matches the dimensions of two Single units. This also means that the version fits the dimensions of a conventional rectangular-grid ceiling.

Very quiet unit in combination with greater capacity
Capacity as the Double combined with low energy consumption, low operating costs, and very quiet operation
Dimensions: 822 x 822 mm, covering enclosure 905 x 905 mm

This model is the preferred choice if the user requires a very quiet unit in combination with greater capacity. Thanks to its larger enclosure, the Big Single has the same capacity as the Double model. Since, however, the key components are included only once in the model, the Big Single combines high capacity with low energy consumption, low operating costs, and very quiet operation.

circular SWIRL air outlet for a perfectly regulated air flow
continuous GreenTech EC fan technology
optimized heat exchanger
quiet operation
intelligent MATRIX control
certified and according to hygiene requirements (VDI 6022)
attractive design
210 - 670 m³/h

The newest type of fan coil unit HyCassette-Geko with SWIRL air outlet technology convinces with its integral concept, that sets new standards: by meeting the highest comfort standards, its intelligent control system and its attractive design, this system is the answer to all your air handling requirements

DencoHappel GmbH

Südstraße 48
44625 Herne

Germany

+49 2325 468-00

+49 2325 468-222

E-Mail

Downloads

Product Brochure - HyCassette-Geko / Cassette-Geko - Fan Coil Units - GB

PR-2015-0019-GB_R3

PDF - 4.58 MB

DH-Points

Heating, cooling, ventilation, and filtering with only one unit
Fast reaching of the desired temperature by a unit with compact dimensions
Flexible temperature-regulation with quiet operation
