Clean Rooms – Ceilings
Wide range of suspended ceilings for all purposes
A part of the clean room assembly is formed also by light lower ceilings used to ensure requirements for cleanliness of the environment in compliance with EN ISO 14 644.
All suspended ceilings feature a tight construction. An integration of lights or HVAC modules is possible.
Light ceiling
for lower classes of clean rooms feature lightweight construction, although overpressure is possible. It shows an absolutely flat surface, as the suspending grid is hidden above the modules and enables easy cleaning.
The basic variant contains the light lower ceiling in colour RAL 9010 and module 625x625mm. Other variants involve the modules 600x600mm and 675x675mm. The ceiling resists a positive pressure in the roomof up to 50Pa. The light lower ceiling is adapted for mounting of the PURO lights and CGx ceiling air outlets. It is designed to be used in health care systems, operating rooms and in hospital utility rooms, as well as in pharmaceutical and other industrial applications of GMP classes C and D.
Cassette ceiling
is designed for higher classes of clean rooms and feature a rigid construction. This allows high over- and underpressure in the room.
Standard module 690/690mm and 690/1380mm for integration of standard CGF air diffuser and PURO lights. Guaranteed resistance to positive pressure of 200Pa, also for negative pressure applications. Suitable for all classes of Clean rooms.
Panel ceiling
is made up of sandwich panels, which are tightly connected and suspended on the roof. This ceiling is suitable for all clean room classes and should be used in locations where an accessible and walkable ceiling is needed (e.g. for maintenance of HVAC components)
Panel Ceiling (ES) - Standard module 1200/2400mm. Guaranteed resistance to positive pressure of 200Pa, also for negative pressure applications. Suitable for all classes of Clean rooms.
Panel Ceiling (GS) - Designed for special fire resistant applications, fire resistance EI60, standard module 1000/3000mm.
